Features
Built for the Real World
Every component is purpose-engineered for durability, safety, and zero-maintenance operation in demanding transportation environments.
Impact Resistant
— 400lb vertical static load at arm end
— 200lb dynamic load rating
— Hinges toward bus on impact, contacts rubber bumper
— Will not detach — eliminates projectile risk
Vandal Resistant
— No exposed wires
— Arm designed for 400 pound static load
— Access cover protects power unit electrical connection
— No pinch points to cause injury
LED Light System
— Each circular light contains 28 high-intensity LEDs per side (112 total)
— 3 LED strips per side in fiberglass light bar
— Dual-sided, individually replaceable circular LED modules
— FMVSS 108 compliant
Zero Maintenance
—Sealed housing and bearings
—No scheduled maintenance required
—Custom structural fiberglass light bar resists impact and the elements
—All stainless steel exposed fasteners
Auto-Reset Capability
— Auto resets 5 seconds after impact
— No manual intervention or tools needed
— Manual stow with automatic locking by pushing toward bus
— Internal lock holds arm securely when retracted
Multiple Configurations
— Available up to 8ft total length
— Standard model extends 6.5ft from bus
— Shorter version for single-lane or parking lots
— Custom lengths available on request
Environmental Protection
IP66 Rated
Complete protection against dust ingress and powerful water jets from any direction.
Vandal Resistant
400lb staic load rating. No exposed wires. Automatic locking.
LED Light System
Circular LED modules contain 28 high-intensity LEDs per side in a sealed housing. FMVSS 108 compliant. Circular LED modules are Individually replaceable.
